Rising Sun

Tremolo

Analog tremolo with tap and ramp capability.

  • Analog design, digital control.

  • Optical-based tremolo.

  • Built for the explorer.

Purchase
Rising Sun BB-2.jpeg

Story of Rising Sun

  • The Rising Sun is a tribute to my Blackfeet (Amsskaapi Piikuni) heritage.

  • The Blackfeet were nomadic, but their movement wasn’t aimless. They traveled with a purpose, knowing where food and resources were plentiful. The teepee served as shelter because of its ability to fit the nomadic lifestyle of the Blackfeet.

  • When setting up camp, the Blackfeet pitched their teepee doors towards the eastern sky. Every morning, the Blackfeet would open their doors so that their prayers could travel to the Rising Sun, which would help the sun reach above the horizon for another day.

  • The Rising Sun artwork looks towards the eastern sky as the sun rises over the horizon.

    -Mike Trombley, Founder

Details

  • Rising Sun

    The Rising Sun is an optical tremolo pedal that expands on the technology found in vintage amplifiers.

    The intuitive interface features volume, waveform, and depth controls for a warm-analog tremolo experience. The Rising Sun includes two modes of operation: tap and ramp.

    Tap mode implements four sub-divisions for tap-tempo capability. Ramp mode allows for smooth transition between two selectable tremolo speeds.

    Continue →

  • Features

    ● Analog-optical tremolo provides vintage tremolo sounds.

    ● Intuitive interface with volume, waveform, and depth controls for tone shaping.

    ● Tap mode with multiple sub-divisions to sync tremolo speed to the tempo of your environment.

    ● Ramp mode allows for smooth transition between two selectable tremolo speeds.

    ● 9-18VDC operation for expanded headroom.

    ● Smart switching system that provides standard on/off latching and momentary operation.

    ● Top-mounted instrument and power jacks designed to save pedalboard space.

    ● Buffered-bypass design to optimize signal integrity with any instrument cable length.

    Continue →

  • Specifications

    Version

    2.0.

    Circuit Design

    Analog.

    Output Audio

    Mono.

    Bypass Switching

    Buffered bypass.

    Switching Methods

    Momentary or latching.

    Power Supply

    9VDC - 50mA (2.1mm - center negative).

    Dimensions

    2.6''x4.77'' (W x L).

Controls and Operations

  • Controls

    Volume

    Controls the overall volume of the signal.

    Waveform

    Sets the waveform to one of the following waveforms:

    Sine, ramp up, ramp down, and square.

    Depth

    Controls the depth of the tremolo.

    Tap and Ramp

    Selects the mode of operation.

    Continue →

  • Tap Mode Operations

    Rate

    Controls the rate of the tremolo.

    Divisions

    Sets the tap tempo to one of the following divisions:

    Half, quarter, eighth and sixteenth.

    Control Switch

    Sets the tempo.

    Continue →

  • Ramp Mode Operations

    R.Time

    Controls the amount of time to ramp between the slow and fast rate.

    Slow (Fast)

    Adjusts the slow and fast rate.

    Changing the Slow and Fast Rates

    1. Rotate the slow (fast) knob to adjust slow rate.

    2. Hold on (hold) and rotate the slow (fast) knob to adjust fast rate.

    Control Switch

    Hold control to adjust the rate of the tremolo from slow to fast. Release control to return the rate back to slow.

    Continue →

  • On (Hold) Operations

    On (Hold) Switch

    Turns the effect on and off or when the effect is on, hold on (hold) to access fast rate.

    Latching Operation

    1. Press and release on (hold) quickly to toggle the effect on and off.

    2. When the effect is on, hold on (hold) to access fast rate.

    Momentary Operation

    1. Hold on (hold) when effect is off to temporarily turn the effect on and release on (hold) to turn the effect off.

Demos
